How To: Determine The Minimum Required Thickness Of A Boiler Drum

In ASME code calculations involving cylindrical components you will be required to determine the minimum required thickness of a boiler drum.

All referenced page numbers are from the 2007 ASME Boiler & Pressure Vessel Code.

Formula

To determine the minimum required thickness of a boiler drum required for various applications you will use a formula contained within ASME Boiler & Pressure Vessel Code PG-27 Cylindrical Components Under Internal Pressure page 10. Specifically PG-27.2.2 page 10

PG-27.2.2 Piping, Drums, and Headers. (based on strength of weakest course) It is important to remember any cylinder with an outside diameter less then 125mm is to be considered tubing and the equation provided in PG-27.2.1 page 8 must be used.

PG-16.3 Minimum Thicknesses It is also important to note that according to PG-16.3 that the minimum thickness of any boiler plate under pressure shall be 1/4in (6mm) except for electric boilers constructed under the rules of Part PEB

PG-27.2.2 Formula to calculate the minimum required thickness:

Outside Diameter Equation

How To: Determine Minimum Required Thickness Of A Boiler Drum Diameter Formula

Inside Radius Equation

How To: Determine The Minimum Required Thickness Of A Boiler Drum Inside Radius Formula

Formula Variables

The symbols used within the PG-27 formulas are contained within paragraph PG-27.3 page 10 and are defined as follows.

C = Minimum allowance for threading and structural stability (mm) (PG-27.4, note 3) page 11

D = Or O.D. is Outside diameter of cylinder (mm) “In this case piping”

E = Efficiency of longitudinal welded joints or of ligaments between openings, whichever is lower (the values allowed for E are listed in PG-27.4, note 1) page 11

e = Thickness factor for expanded tube ends (mm) (see PG-27.4, note 4) page 11

P = Maximum allowable working pressure “Gauge Pressure” (MPa) (see PG-21, refers to gauge pressure)

R = Inside radius of cylinder (mm) “In this case boiler drum”

S = Maximum allowable stress value at the operating temperature of the metal (Section II, Part D, Table 1A. See PG-27.4, note 2) page 11. It is important when determining the maximum allowable stress value to check (PG-6 plate materials) page 4 and (PG-9 boiler tube materials) page 5 before starting calculations as this information will determine the correct stress table to use by indicating whether the material is carbon steel or an alloy steel.

t = minimum required thickness (mm) (see PG-27.4, note 7) page 12

y = temperature coefficient (see PG-27.4, note 6) page 11

[table id=1 /]

How to: Determine the minimum required thickness of a boiler drum questions

Note: All code questions are to be calculated in (mm) and (MPa) unless otherwise stated. Convert accordingly and properly before the calculation.

Question #9

How To: Determine The Minimum Required Thickness Of A Boiler Drum - 2A1 Question #9
2A1 Question #9
How To: Determine The Minimum Required Thickness Of A Boiler Drum - 2A1 Solution #9
2A1 Solution #9

Question #10

How To: Determine The Minimum Required Thickness Of A Boiler Drum - 2A1 Question #10
2A1 Question #10
How To: Determine The Minimum Required Thickness Of A Boiler Drum - 2A1 Solution #10
2A1 Solution #10



2A1 Power Engineering Exam Study Material

Summary

Did the examples provided help you understand how to calculate the minimum required thickness for a boiler drum? If not let me know why and of additional questions, or ideas to improve the content provided.
